RB21F Flush Diaphragm Pressure Transmitter

Send Inquiry

Request To Call Back

RB21F Flush Diaphragm Pressure Transmitter

Name: RB21F Flush Diaphragm Pressure Transmitter
Brand: RBA OPTISYNC PRIVATE LIMITED
Price: 6120 INR
Availability: InStock

Price 6120 INR/ Piece

Get a Price/Quote

MOQ : 2 Pieces

RB21F Flush Diaphragm Pressure Transmitter Specification

Connectivity Type
2-wire / 4-20mA

Protection
IP65

Pressure Range
0~10 Bar

Sensor Type
Piezoresistive

Diameter
50 mm (Diaphragm)

Resolution
0.01 Bar

Capacity
10 Bar (Max)

Equipment Type
Flush Diaphragm Pressure Transmitter

Application Media
Liquids, viscous fluids, slurries

Temperature Range
-20C to 80C

Measurement Range
0~10 Bar

Humidity %
95% RH (non-condensing)

Current Range
4-20mA

Material
Stainless Steel 316L

Power Supply
24V DC

Power Consumption
< 2W

Accuracy
0.5% F.S.

Display Type
4-digit LCD

Range
0~10 Bar

Process Connection
G1/2" or customized

Mounting Type
Flush Mount

Zero/Span Adjustment
External via potentiometers

Output Signal
4-20mA (standard), others optional

Vibration Resistance
10g (20-2000Hz)

Weight
Approx. 350g

Explosion Proof
Available as optional

Electrical Connection
Cable outlet or DIN connector

Overload Pressure
150% of F.S.

Response Time
<50ms

RB21F Flush Diaphragm Pressure Transmitter Trade Information

Minimum Order Quantity
2 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About RB21F Flush Diaphragm Pressure Transmitter

Jump on the opportunity to own the RB21F Flush Diaphragm Pressure Transmitter, a crowning solution for precise liquid, viscous fluid, and slurry measurement. With a gorgeous stainless steel 316L construction and a perfect flush mount design, this transmitter ensures reliability and accuracy up to 0.5% F.S. Order today at an affordable price-enjoy flexible process connections, rapid response time (<50ms), and robust vibration resistance. Offering explosion-proof options and zero/span adjustment, this transmitter is ideal for demanding industrial environments across India. Perfect for your measurement needs!

Versatile Applications & Competitive Advantages

The RB21F Flush Diaphragm Pressure Transmitter is perfect for industries dealing with hygiene-critical applications, viscous or corrosive media, including the food, pharmaceutical, and chemical sectors. Its primary competitive advantages include high accuracy, rugged stainless steel 316L build, and easy zero/span external adjustment. This equipment suits continuous or batch processing operations, offering reliability in both indoor and outdoor environments. Use type is adaptable-ideal for both new installations and system upgrades.

Packaging, Certifications & Sample Availability

Arrival of each RB21F transmitter guarantees secure packaging-ensuring product integrity throughout domestic markets. Express shipping can be coordinated to speed up your project timelines. The product complies with industry certifications, confirming its trustworthy performance and safety standards. Sample units are available upon request, allowing you to evaluate the transmitter's capabilities prior to full-scale orders. Order with confidence from a reliable importer, manufacturer, supplier, and trader within India.

FAQ's of RB21F Flush Diaphragm Pressure Transmitter:

Q: How does the RB21F Flush Diaphragm Pressure Transmitter handle demanding applications?

A: The RB21F's flush mount design combined with stainless steel 316L construction and optional explosion-proof feature provide robust performance in harsh and hygienic environments. It's especially effective for measuring pressure in liquids, viscous fluids, or slurries.

Q: What types of output signals are available for the RB21F model?

A: The standard output for RB21F is 4-20mA (2-wire), but other optional output configurations can be customized to fit your process requirements.

Q: When should zero/span adjustment be performed and how is it done?

A: Zero and span adjustments can be carried out externally using potentiometers. These adjustments are recommended during initial setup or maintenance to ensure optimal transmitter accuracy.

Q: Where can this pressure transmitter be installed?

A: The RB21F is suitable for flush mounting in pipelines, tanks, or vessels within industrial plants requiring reliable pressure measurement in India's diverse environments.

Q: What are the key benefits of choosing this affordable pressure transmitter?

A: Ordering today provides you a high-accuracy (0.5% F.S.), vibration-resistant (10g) device with fast response time, IP65 protection, and flexible process and electrical connections-ensuring lasting value and versatile usage.

Q: How is the RB21F transmitter packaged and shipped for arrival?

A: The product is securely packaged to prevent damage, with options for express shipping to domestic markets, ensuring prompt and safe arrival at your location.
